4101 LEVEL IV

SKU: 4101-SP-SC-S

Hesco

Regular price $271.00 $258.00 Sale

Don’t like the price?

Contact Us
Lightweight ceramic/Spectra® design. Water repellant polyurethane coated 1000 Denier CORDURA® fabric finish. Other size plates available upon request.  Plates sold INDIVIDUALLY.
This Product is subject...
Learn More >
Color
Black
Plate Size and Cut
7 7
Available at checkout

Lightweight ceramic/Spectra® design. Water repellant polyurethane coated 1000 Denier CORDURA® fabric finish.

Other size plates available upon request.  Plates sold INDIVIDUALLY.

This Product is subject to ITAR/EAR Export Controls. Please visit our ITAR/EAR page (click here) or Contact Us for more Information.

SPECIFICATIONS

  • 1.8 lb (1.19") - 6x6 Side Plates
  • Made in the USA
  • Tested to NIJ Standard–0101.06
  • Stand Alone
  • Single-Curve
  • Advanced composite materials
  • Lightweight ceramic / Spectra® design
  • Highly durable, water resistant polyurethane coated Cordura® fabric finish

LEAD CORE

  • 5.56 x 45 mm - M193
    Max Velocity 3280 ft/s (1000 m/s)
  • 7.62 x 39 mm - M67
    Max Velocity 2410 ft/s (735 m/s)
  • 7.62 x 51 mm - M80
    Max Velocity 2810 ft/s (856 m/s)
  • 7.62 x 63 mm - JSP
    Max Velocity 2794 ft/s (852 m/s)

MILD STEEL CORE

  • 5.56 x 45 mm - M855 . SS109
    Max Velocity 3150 ft/s (960 m/s)
  • 7.62 x 39 mm- M43
    Max Velocity 2410 ft/s (735 m/s)
  • 7.62 x 54R - LPS
    Max Velocity 2832 ft/s (863 m/s)

ARMOR PIERCING CORE

  • 7.62 x 39 mm - API
    Max Velocity 2410 ft/s (735 m/s)
  • 7.62 x 54R B-32 - API
    Max Velocity 2850 ft/s (869 m/s)
  • 7.62 x 51 mm - M61
    Max Velocity 2830 ft/s (863 m/s)
  • 7.62 x 63 mm - AP M2 **
    Max Velocity 2910 ft/s (887 m/s)

ENHANCED PERFORMANCE

  • 5.56 x 45 mm - M855A1
    Max Velocity 3180 ft/s (969 m/s)
  • 7.62 x 51mm - M80A1
    Max Velocity 3050 ft/s (930 m/s)

    MANUFACTURING TOLERANCES

    Thickness dimensions are ± 1/8 in (± 3 mm). Width and length dimensions are +0.00 to -0.25 in (+0.00 to -6 mm). All weights are ± 5%.

    HESCO TESTING PROTOCOL

    NIJ Certification of hard armor requires submission of 10” x 12” test plates which must demonstrate the ability to defeat specific rounds tested to a valid NIJ shot pattern, after exposure to a stringent conditioning protocol to simulate aging and wear. Level III requires six M80 rounds per plate.

    Level IV requires one AP M2 per plate. NIJ’s process provides for the inclusion of other size torso plates of identical construction to be included under the Certification without further NIJ testing.

    Hesco holds itself to a higher standard by publishing the minimum number of shots that each size plate can be expected to defeat under similar NIJ testing methods, as well as listing many additional threats not addressed under the NIJ Certification process. The minimum number of shots are shown in the Threat Performance Matrix.
